Eaton AE566-6 Hose

Eaton Aeroquip AE566-6 is a -6 medium-pressure PTFE hose with an integral braided polyester chafe guard. Supplied in continuous-length quantity by the foot, it is intended for professional aerospace fluid-conveyance hose fabrication and maintenance requirements.

The integral polyester braid is designed to add chafe resistance with minimal increase in outside diameter while retaining hose flexibility.

• Manufacturer part number: AE566-6
• Hose size: -6; nominal tube size 9.5 mm
• Minimum hose inside diameter: 7.56 mm
• Maximum hose outside diameter: 14.19 mm
• Maximum operating pressure: 10.34 MPa (1,500 psi)
• Proof pressure: 20.68 MPa (3,000 psi)
• Minimum burst pressure at room temperature: 62.05 MPa (9,000 psi)
• Minimum bend radius: 101.6 mm
• Temperature range: -54°C to +149°C
• Approximate weight: 0.061 kg per foot

Please verify the required hose specification, end-fitting configuration, system-fluid suitability and installation requirements against the applicable technical data and approved maintenance documentation before use.
