Jeppesen Pj-1 Rotating Azimuth Plotter

Jeppesen Pj-1 Rotating Azimuth Plotter

https://www.roctexo.com/web/image/product.template/4186/image_1920?unique=d6888b8
Part numbers : RX1-13-21726 , 10009524 , 10009524-001 , 13-21726
Unit of Measure: EA

18.85 EUR / EA 18.85 EUR 18.85 € excl. VAT

18.85 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
21 EA available on request, fees apply
Special order from vendor stock.

The Jeppesen PJ-1 Rotating Azimuth Plotter is a manual flight-planning tool designed to simplify true-course measurement and magnetic-course determination by rotating the azimuth scale.

Its clear, elongated format supports practical chart work and route-planning tasks. The plotter includes scales for sectional, terminal-area and WAC charts, with statute-mile and nautical-mile references.

  • Manufacturer part number: 10009524-001
  • Rotating azimuth for true-course and magnetic-course determination
  • Approximate overall size: 83 x 330 mm
  • Approximate azimuth diameter: 86 mm

Suitable for pilots, flight-training organisations and aviation operations requiring a conventional plotting aid for manual navigation planning.
