Brackett Bell 214St Hydraulic Rear Wheels

Image for illustration only. It may show a product series rather than the exact product offered.

Brackett Bell 214St Hydraulic Rear Wheels

https://www.roctexo.com/web/image/product.template/86026/image_1920?unique=585cd5b
Part numbers : RX1-13-16071 , BDW-214ST , 13-16071
Unit of Measure: EA

10353.26 EUR / EA 10353.26 EUR 10,353.26 € excl. VAT

10353.26 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The Brackett Aero Filters BDW-214ST is a hydraulic rear-wheel solution designed for Bell 214ST helicopters. It is intended to support ground handling and incorporates a simple hydraulic bottle-jack arrangement.

  • Manufacturer part number: BDW-214ST
  • Hydraulic operation using an 8-ton bottle jack
  • Two eyebolt attachment points compatible with 412 mm and 457 mm centres
  • Designed for a 102 mm skid-tube diameter
  • Approximate skid lift: 76 mm
  • Approximate dimensions: 48 × 51 × 53 cm
  • Approximate weight: 43 kg per side
  • Orange powder-coated finish

Please verify the required configuration, installation requirements and suitability against the applicable aircraft maintenance data before purchase or use.
