The Gripper II Wireless Cable Tension Meter For Auto Pilot-Bridal Cables

The Gripper II CTR-BCWL-60 from Sprague Instruments is a wireless digital cable tension meter designed for measurement of light, small-diameter autopilot servo bridle cables. Its separate sensor and handheld display allow the technician to observe tension while making adjustments in confined installation areas.

The meter covers a 10–60 lb tension range and supports 1/16 in, 3/32 in and 1/8 in cable sizes. Real-time readings are transmitted by Bluetooth Low Energy 4.2 to the display unit at distances of up to 10 m. The display provides tension, selected cable size, temperature and battery-status information.

• Manufacturer part number: CTR-BCWL-60
• Wireless digital bridle-cable tension measurement
• Tension range: 10–60 lb
• Resolution: 1 lb
• Stated accuracy: ±3% of full scale
• Supported cable sizes: 1/16 in, 3/32 in and 1/8 in
• Selectable temperature display in °C or °F
• Compact sensor head: approximately 64 × 32 × 38 mm

The supplied set is described as including a display unit, sensor unit, rechargeable batteries, 5 V charging adapter, user manual and carrying case.
