Vividia Ablescope Va-980

Vividia AbleScope VA-980 v5 is a USB digital articulating borescope for detailed visual inspection of difficult-to-access internal areas. Its semi-rigid, mouldable metal probe helps the operator position the camera where a stable, extended reach is needed.

The 8.5 mm probe features continuously adjustable 0–180° articulation, allowing the camera to look back toward areas beyond the initial line of entry. Integrated white LED illumination and a 1 MP CMOS sensor support viewing, still-image capture and video recording during inspection work.

• Manufacturer part number: VA-980
• Probe diameter: 8.5 mm
• Probe length: 81.5 cm
• Semi-rigid, bendable gooseneck-style metal probe
• Articulation range: 0–180°, with angle locking/unlocking
• Illumination: 8 integrated white LEDs
• Still image resolution: 1280 × 720 pixels, JPG format
• Video resolution: 1280 × 720 pixels at 30 fps, AVI format
• Viewing angle: 120°
• Focus range: approximately 5 mm to infinity
• USB 2.0 interface with 2 m USB cable

The VA-980 v5 connects by USB to a suitable computer, tablet or phone. Manufacturer-listed supported systems include Windows, macOS, Chromebook and Android; Android use requires a suitable OTG connection and device support for USB video devices.

Manufacturer-listed contents include the VA-980 v5 borescope, OTG cables, plastic case and user manual. Relevant documentation includes the Vividia AbleScope VA-400/VA-980 user guide and Vividia AbleScope Viewer software user guide.
