Diff Cylinder Press Test Cmbo >5Bo

https://www.roctexo.com/web/image/product.template/101324/image_1920?unique=758f503
Part numbers : RX1-12-02347 , 2EM-60 , 12-02347
Unit of Measure: EA

152.45 EUR / EA 152.45 EUR 152.45 € excl. VAT

152.45 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The 2EM-60 is a differential cylinder pressure tester with an integrated master orifice, intended for comparative cylinder leakage checks on large-bore engines. The master-orifice arrangement allows the observed leakage reading to be compared with a calibrated reference.

  • Manufacturer part number: 2EM-60
  • Large-bore configuration with 0.060 in master orifice
  • Precision gauges matched within ±2%
  • Includes an 18 mm spark-plug adapter and approximately 610 mm pressure hose
  • Supplied with instructions and a form-fitted protective hard case
  • Recorded product weight: 1.86 kg

For use, selection and interpretation of test results, follow the applicable engine manufacturer maintenance data and procedures.

Contact Us

Terms and Conditions

Share

Overview

The Model 2EM-60 Differential Cylinder Pressure Tester combines the features of the popular 2E tester and a Master Orifice into one tool. Now you can conveniently check your engine's leakdown rate against a calibrated standard to instantly determine if your engine's cylinder leakage is within the manufacturer's limits. Specifications: Orifice size is .060". precision gauges matched to within +/-2%. Includes 18MM Spark Plug Adapter, 24" pressure hose, and complete instructions. Protective form-fitted hard case included. Factory calibrated. Letter of certification available upon request.

This differential pressure tester has a .060" orifice and is intended for use with engines whose bore diameters exceed 5" per AC43.13 REV 1B. However, Lycoming and Continental service specifications call for the use of a standard tester (with a .040" orifice) even if their engine’s bore diameters exceed 5", and for those engines you must comply with the manufacturer's specifications and use a standard tester such as the 2EM instead of this unit.
