RAMI Communication Antenna - TSO - Gloss Black - AV-530

RAMI Communication Antenna - TSO - Gloss Black - AV-530

https://www.roctexo.com/web/image/product.template/294700/image_1920?unique=11fc194
Part numbers : RX1-11-21290 , AV-530-GB , 11-21290
Unit of Measure: EA

241.26 EUR / EA 241.26 EUR 241.26 € excl. VAT

241.26 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The RAMI AV-530-GB is a gloss black VHF airborne communications antenna for the 118–137 MHz band. Designed for broadband communications, it combines a die-cast aluminium base with a tapered stainless-steel whip to help reduce drag at higher airspeeds.

The antenna is supplied with a weather-sealing gasket and mounting hardware. Its gloss black finish is part of RAMI’s AV-530(-GB) configuration.

  • Manufacturer part number: AV-530-GB
  • Roctexo part number: RX1-11-21290
  • Frequency range: 118–137 MHz
  • Impedance: 50 ohms nominal
  • Polarisation: vertical
  • Radiation pattern: omni-directional
  • Connector: BNC female
  • Maximum VSWR: 2.5:1
  • RF power capacity: 25 W
  • Maximum height: approximately 578 mm
  • FAA TSO: C37d and C38d

Installation should be carried out in accordance with the applicable aircraft maintenance data and the manufacturer’s instructions. RAMI documentation is available for reference: data sheet, footprint drawing, outline drawing and installation instructions.
