Astro Tool - Positioner (M22520/2-06)

Astro Tool - Positioner (M22520/2-06)

https://www.roctexo.com/web/image/product.template/134203/image_1920?unique=717dbc1
Part numbers : RX1-11-20359 , 615722 , 11-20359
Unit of Measure: EA

92.43 EUR / EA 92.43 EUR 92.43 € excl. VAT

92.43 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 1 EA ready to ship on Thursday 2026-09-17
Order before 16:00 CET Tomorrow
Up to 2 EA ready to ship on Monday 2026-09-21
Order before 16:00 CET Tomorrow
2 EA available on request, fees apply
Special order from vendor stock.

The Astro Tool 615722 is a DMC K41 bayonet positioner, identified as M22520/2-06. It is used with the Astro Tool 615717 crimp tool frame to locate crimps on size 22 female socket contacts.

Specified for contacts installed in MIL-C-24308 subminiature rectangular connectors and MIL-C-38999 circular connectors.

  • Manufacturer part number: 615722
  • Designation: M22520/2-06
  • Reference designation: DMC K41
  • Positioner type: Bayonet positioner
  • For use with Astro Tool 615717 crimp tool frame
  • Referenced contacts include MS27491-22, MS27492-22, M24308/12-1, M39029/57-354 through M39029/57-356, M39029/89-494 through M39029/89-497, and M39029/92-351

For part-number verification, consult the Astro Tool crimp tool cross-reference.
