Shielded 20GA White Wire M27500-20TG4T14

Shielded 20GA White Wire M27500-20TG4T14

https://www.roctexo.com/web/image/product.template/70176/image_1920?unique=3a5d290
Part numbers : RX1-11-18776 , J4161 , M27500-20TG4 , M27500-20TG4T14 , 11-18776
Unit of Measure: FT

1.53 EUR / FT 1.53 EUR 1.53 € excl. VAT

1.53 EUR / FT excl. VAT

Not Available For Sale

This combination does not exist.

Availability
58 FT ready to ship Tomorrow
Order before 15:30 CET Tomorrow
Up to 8,045 FT ready to ship on Thursday 2026-08-13
Order before 15:30 CET Tomorrow
Up to 9,094 FT ready to ship on Monday 2026-08-17
Order before 15:30 CET Tomorrow
4,062 FT available on request, fees apply
Special order from vendor stock.

Shielded and jacketed 20 AWG white aircraft wire in the M27500-20TG4T14 configuration. Suitable for aviation electrical wiring work where a four-conductor, shielded cable construction is specified.

  • Part numbers: M27500-20TG4T14; M27500-20TG4; J4161
  • 20 AWG, 4-conductor construction
  • Stranded tin-plated copper conductors
  • White ETFE (Tefzel) insulation and outer jacket
  • Tin-plated copper braid shield with 85% coverage
  • Temperature rating: up to 150°C
  • Voltage rating: 600 V
  • Conforms to MIL-C-27500; stated as replacing MIL-C-7078/3
  • Supplied by the foot

Please confirm the required wire specification, conductor count, shielding arrangement and colour code against the applicable maintenance data before installation.
