Garmin GSB 15 Type C Side 010-02544-51

The Garmin GSB 15 is a compact, panel-mount USB charging hub designed for aircraft installations. Garmin part number 010-02544-51 is the dual USB Type-C version with the power input connector positioned on the side, supporting installation where rear depth or wiring access is limited.

Two USB Type-C ports provide up to 27 W of output per port simultaneously and use USB Power Delivery technology to optimise power delivery for connected devices. The unit is designed for 14 V or 28 V aircraft electrical systems and incorporates short-circuit and over-temperature protection. Dimmable halo lighting around the ports supports device connection in low-light cockpit or cabin environments.

• Garmin part number: 010-02544-51
• Configuration: dual USB Type-C ports
• Power input location: side connector
• Maximum output: up to 27 W per port
• Input voltage: 14 V or 28 V
• Approximate dimensions: 38 x 39 x 21 mm
• Designed to fit a 1-inch instrument cutout; optional adapter plates are available separately for larger standard panel cutouts.

This standard configuration includes the Garmin GSB 15 connector kit. Installation should be performed in accordance with the applicable Garmin installation documentation and aircraft-approved data.

Documentation: Garmin GSB 15 Installation Manual
