Garmin GSB 15 Type A & C Side 010-02544-31

The Garmin GSB™ 15, part number 010-02544-31, is a compact aircraft USB charging hub configured with one USB Type-A port and one USB Type-C port. This version has a side-mounted power input connection, intended to help accommodate installations where rear clearance is limited.

Designed for 14 V or 28 V aircraft electrical systems, the GSB 15 provides charging capability for portable electronic devices used in the cockpit or cabin. The USB Type-A/Type-C configuration supports up to 27 W power output per port and incorporates USB Power Delivery technology to optimise output for a connected device.

• Garmin manufacturer part number: 010-02544-31
• USB ports: one USB Type-A and one USB Type-C
• Power input location: side
• Input voltage: 14 V or 28 V
• Maximum output: up to 27 W per port
• Dimmable halo lighting around the ports
• Short-circuit and over-temperature protection

The compact GSB 15 design fits a 25.4 mm instrument hole and may be installed with optional adapter plates or mounting accessories where applicable. Garmin documentation identifies 010-02544-31 as the standard part number for this Type-A and Type-C, side-input configuration; the standard configuration includes the connector kit.

Installation must be performed in accordance with the applicable Garmin installation manual and aircraft-approved data.
