uAvionix AV-20-S Multi-Function Display Certified

The uAvionix AV-20-S is a compact multi-function cockpit display for certified-aircraft applications. Designed for installation in a standard 2¼-inch round instrument opening, it combines timekeeping, flight-information and monitoring functions in a single panel-mounted unit.

Manufacturer part number: UAX-90050-01

The AV-20-S provides a configurable display with a matte screen and automatic brightness adjustment for clear viewing in changing ambient light conditions. An internal battery supports operation for up to 30 minutes in the event of aircraft power loss, under the manufacturer’s stated test conditions.

• Angle-of-attack display with configurable audio alerts and peak indication
• G-meter with audio alerts and peak indication
• Attitude, roll/pitch and slip/skid indication
• GMT/local clock and dual count-up/count-down timers
• Engine run timer and flight timer
• Bus-voltage, outside-air-temperature and density-altitude displays
• True-airspeed display
• 9-pin male D-sub electrical connector and ¼-inch OD quick-connect pneumatic connections

The manufacturer identifies the AV-20-S as FAA NORSEE (Non-Required Safety Enhancing Equipment) approved. This FAA status does not by itself establish EASA approval or installation acceptance in Europe; review the applicable approved data, aircraft documentation and national regulatory requirements before installation.

Relevant manufacturer documentation:

• AV-20 Installation Manual: UAV-1003613-001
• AV-20 Pilot’s Guide: UAV-1003614-001
• uAvionix AV-20 NORSEE Approval documentation
