TE Soldersleeve With Pre-Installed Lead Cwt-5-W122-5

TE Soldersleeve With Pre-Installed Lead Cwt-5-W122-5

https://www.roctexo.com/web/image/product.template/85522/image_1920?unique=9065fd1
Part numbers : RX1-11-16370 , CWT-5-W122-5 , 11-16370
Unit of Measure: EA

2.22 EUR / EA 2.22 EUR 2.22 € excl. VAT

2.22 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 163 EA ready to ship on Monday 2026-08-17
Order before 17:00 CET Tomorrow
Up to 491 EA ready to ship on Thursday 2026-08-20
Order before 17:00 CET Tomorrow
3,060 EA available on request, fees apply
Special order from vendor stock.

The TE Connectivity RAYCHEM CWT-5-W122-5 is a SolderSleeve shield terminator supplied with a pre-installed lead. It provides a compact solder termination solution for shielded cable work, with splash-protection properties and a thermochromic temperature indicator.

The pre-installed lead is white, tin-plated, stranded XL polyethylene wire with a nominal conductor size of 0.38 mm².

  • Manufacturer part number: CWT-5-W122-5
  • Product family: RAYCHEM CWT SolderSleeve shield terminators
  • Pre-installed lead: Yes
  • Expanded inside diameter: 4.32 mm minimum
  • Recovered inside diameter: 2.01 mm maximum
  • Compatible jacket diameter: 4.3 mm
  • Minimum shield outside diameter: 2.0 mm
  • Overall length: 29.3 mm
  • Maximum operating temperature: 125 °C
  • Maximum wire temperature: 105 °C

For installation and design activity, refer to the applicable TE Connectivity product drawing and CWT installation documentation.
