AeroLEDs Pulsar 650 Wingtip Forward Position / Anti-Collision Light Left Certified (28V)

The AeroLEDs Pulsar 650 is a left-hand, red LED wingtip assembly combining forward position and anti-collision lighting for 28 VDC aircraft electrical systems. This certified Pulsar 650 configuration is identified by manufacturer part number 11-1280-B-24-L.

Its compact wingtip-light design incorporates a patented three-position mounting bracket. For the 28 VDC version, AeroLEDs specifies 0.4 A current draw for the position light and 0.4 A average / 3.05 A peak for the anti-collision light.

• Manufacturer: AeroLEDs
• Series: Pulsar 650
• Function: Red forward position light and anti-collision light
• Installation side: Left
• Nominal electrical system: 28 VDC
• Manufacturer part number: 11-1280-B-24-L
• Approximate dimensions: 102 × 48 × 38 mm
• Manufacturer-stated unit weight: approximately 0.11 kg
• Manufacturer-listed approval basis: FAA-TSOA/STC

For anti-collision operation, AeroLEDs notes that this red configuration requires additional wiring. Refer to the current manufacturer installation manual, installation template and applicable approved data before installation. Regulatory acceptance and aircraft applicability should be confirmed for the intended installation.
