T3-12A Servo Sys.With Full Pos In

Image for illustration only. It may show a product series rather than the exact product offered.

T3-12A Servo Sys.With Full Pos In

https://www.roctexo.com/web/image/product.template/114415/image_1920?unique=4144e40
Part numbers : RX1-11-11615 , T3-12A-TS , 11-11615
Unit of Measure: EA

552.85 EUR / EA 552.85 EUR 552.85 € excl. VAT

552.85 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 4 EA ready to ship on Monday 2026-10-05
Order before 17:00 CET on Friday 2026-10-02
Up to 6 EA ready to ship on Thursday 2026-10-08
Order before 17:00 CET on Friday 2026-10-02
3 EA available on request, inbound freight fee of 60 EUR applies
Special order from vendor stock.

The Ray Allen T3-12A-TS is an electric trim servo system with full position indication for experimental-aircraft installations. It combines a T3-series actuator with a clevis/pushrod kit, rocker switch and LED position indicator.

  • Manufacturer part number: T3-12A-TS
  • Roctexo part number: RX1-11-11615
  • Actuator supply: 12–14 VDC
  • Output-shaft travel: 31 mm
  • Travel time: 19 seconds at 13.5 VDC
  • T3 jackscrew actuator design; the output shaft locks in position when electrical power is removed.
  • RP4 LED position indicator with servo-feedback position display.

The system documentation identifies an RC8-7 clevis/pushrod kit, RS2 rocker switch and RP4 LED position indicator. Refer to the Ray Allen T2/T3 Trim System Installation Instructions for installation, wiring and dimensional information. Verify suitability, installation details and regulatory requirements for the intended aircraft application before fitment.
