24V Port Power Supply 20 Amp Cess Plg & Battery Clips

Image for illustration only. It may show a product series rather than the exact product offered.

24V Port Power Supply 20 Amp Cess Plg & Battery Clips

https://www.roctexo.com/web/image/product.template/36619/image_1920?unique=182fd28
Part numbers : RX1-11-05086 , JAC2024H-CEC , ASS-11-05086 , 11-05086
Unit of Measure: EA

539.38 EUR / EA 539.38 EUR 539.38 € excl. VAT

539.38 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
1 EA ready to ship Tomorrow
Order before 15:30 CET Tomorrow
Up to 12 EA ready to ship on Thursday 2026-10-29
Order before 15:30 CET Tomorrow
Up to 21 EA ready to ship on Monday 2026-11-02
Order before 15:30 CET Tomorrow
19 EA available on request, inbound freight fee of 60 EUR applies
Special order from vendor stock.

The Schauer JAC2024H-CEC is a portable 24 V, 20 A ground power supply and automatic battery charger for ground servicing and cockpit avionics operation.

It is supplied with a Cessna-style 3-pin external-power connector and battery clips, providing a practical connection option for aircraft external-power receptacles and direct battery charging.

  • 24 V DC, 20 A output
  • Cessna-style 3-pin aircraft power connector
  • Battery clip adapter included
  • Automatic 3-stage charging profile: constant current, constant voltage and float/maintenance mode
  • Suitable for supported 24 V lead-acid battery types, including conventional, maintenance-free, deep-cycle, gel and valve-regulated batteries
  • Current limiting, reverse-polarity protection and short-circuit protection
  • Aluminium enclosure

Manufacturer part number: JAC2024H-CEC.

This unit is intended for ground power and battery charging applications; it is not intended for engine starting or landing-gear actuation.

Documentation: Manufacturer product information.
