12V Port Power Supply 25 Amp Piper Plg & Battery Clips

12V Port Power Supply 25 Amp Piper Plg & Battery Clips

https://www.roctexo.com/web/image/product.template/3405/image_1920?unique=99a391e
Part numbers : RX1-11-05085 , JAC2512-PC , 11-05085
Unit of Measure: EA

323.59 EUR / EA 323.59 EUR 323.59 € excl. VAT

323.59 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 8 EA ready to ship on Monday 2026-08-17
Order before 17:00 CET Tomorrow
Up to 9 EA ready to ship on Thursday 2026-08-20
Order before 17:00 CET Tomorrow
12 EA available on request, fees apply
Special order from vendor stock.

The Schauer JAC2512-PC is a 12 V, 25 A portable ground power supply and battery charger supplied with a Piper-style single-pin connector and battery clips. It is intended to provide 12 V DC power for ground servicing and avionics operation, while the battery-clip adapter enables direct connection for battery charging.

The unit uses a three-stage charging profile with constant-current, constant-voltage and float/maintenance stages. It is designed for lead-acid battery types including flooded, AGM and gel batteries.

  • Manufacturer part number: JAC2512-PC
  • Roctexo part number: RX1-11-05085
  • Nominal DC output: 12 V
  • Maximum DC current: 25 A
  • Supplied with Piper-style single-pin connector and battery clips
  • 115/230 V AC, 50/60 Hz input
  • Aluminium enclosure
  • Current limiting, reverse-polarity and short-circuit protection
  • Float/maintenance charging mode for connected lead-acid batteries

Please consult the applicable aircraft maintenance data and the manufacturer’s instructions before use. This unit is a ground power supply and battery charger; it is not intended for engine starting.

Contact Us

Terms and Conditions

Share

Overview

These portable power supplies are an excellent way to power your avionics on the ground while you train or practice in the cockpit. Especially helpful in learning how to operate glass cockpit avionics and panel mount GPS units.

To use the Portable Power Supply plug the cord into an AC wall outlet, and then connect the Piper style plug into the external power receptacle on your aircraft. Furnished with Piper style plug. Manufactured in U.S.A.

This unit can also be used as a battery charger, by using the battery clip adapter which is provided with the unit.

Features

  • Charge control: constant current charge to a constant voltage then to a float standby.
  • Current Limiting.
  • Fully automatic 3 stage charger can be left on the battery in maintaining/float mode.
  • Can be set for any type lead acid battery, including conventional, maintenance free, deep cycle, gelled-type, valve regulated batteries.
  • Continuous - 100% duty cycle.
  • Low voltage start: will start charging a deeply discharged battery with terminal voltage less than 4 volts.
  • Reverse polarity and short circuit proof.
  • Aluminum caset.
