TE P&B Circuit Breaker W23-X1A1G-25

TE P&B Circuit Breaker W23-X1A1G-25

https://www.roctexo.com/web/image/product.template/9052/image_1920?unique=97c093d
Part numbers : RX1-11-04118 , W23-X1A1G-25 , 11-04118
Unit of Measure: EA

50.75 EUR / EA 50.75 EUR 50.75 € excl. VAT

50.75 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
2 EA ready to ship Tomorrow
Order before 15:30 CET Tomorrow
Up to 16 EA ready to ship on Thursday 2026-09-03
Order before 15:30 CET Tomorrow
Up to 27 EA ready to ship on Monday 2026-09-07
Order before 15:30 CET Tomorrow
58 EA available on request, fees apply
Special order from vendor stock.

The TE Connectivity Potter & Brumfield W23-X1A1G-25 is a 25 A, single-pole thermal circuit breaker from the W23/W31 series. It features a black push-pull actuator, non-illuminated construction and series-trip circuit function.

  • Manufacturer part number: W23-X1A1G-25
  • Current rating: 25 A
  • Operating voltage: 240 VAC and 50 VDC
  • Thermal circuit breaker with series-trip function
  • Single-pole, push-pull button actuator
  • Trip time at 200% load: 6–22 seconds
  • 8-32 screw terminals positioned at 90° to each other
  • Threaded 3/8-24 mounting bushing, approximately 9.5 mm long
  • Panel cut-out diameter: approximately 9.5–9.8 mm
  • Interrupt capacity: 1,000 A at 50 VDC or 120 VAC

For installation and technical verification, consult the TE Connectivity W23/W31 Series Datasheet and applicable electrical-system documentation.

Contact Us

Terms and Conditions

Share

P & B Part No.AMP
Rating		BeechCessnaPiperPart No.
W23X1A1G2525CB-2325A-45466011-04118

Overview

These bi-metallic single pole breakers weigh less than 2 oz. and are especially suitable for homebuilt aircraft. Used as original equipment in Beech, Cessna and Piper aircraft. Maximum operating voltages: 32 VDC and 250 VAC (to 400 Hz).

Push/Pull Actuator Thermal Circuit Breaker
    0.5 amp to 50 amp ratings may be used as on/off switch
    Cannot be reset against overload
    W23 has visible trip indicator
    Screw termination
    Trip-free operation
