TE P&B Circuit Breaker W31-X2M1G-40

TE P&B Circuit Breaker W31-X2M1G-40

https://www.roctexo.com/web/image/product.template/26968/image_1920?unique=99a391e
Part numbers : RX1-11-03935 , W31-X2M1G-40 , 11-03935
Unit of Measure: EA

62.53 EUR / EA 62.53 EUR 62.53 € excl. VAT

62.53 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 25 EA ready to ship on Monday 2026-08-17
Order before 17:00 CET Tomorrow
Up to 71 EA ready to ship on Thursday 2026-08-20
Order before 17:00 CET Tomorrow
65 EA available on request, fees apply
Special order from vendor stock.

The TE Connectivity / Potter & Brumfield W31-X2M1G-40 is a 40 A, single-pole thermal circuit breaker from the W23/W31 series. It has a series-trip circuit function and a silver, non-illuminated toggle actuator.

Manufacturer part number: W31-X2M1G-40
TE Connectivity internal part number: 4-1393247-1

  • Current rating: 40 A
  • Operating voltage: up to 240 VAC or 50 VDC
  • Thermal circuit breaker with series-trip function
  • Single-pole configuration
  • Toggle-style, non-illuminated silver actuator
  • 8-32 screw terminals positioned at 90° to each other
  • Approx. 12 mm panel cut-out diameter
  • Trip time at 200% of rated current: 6–22 seconds

Suitable for applications requiring a panel-mounted circuit protection device with manual toggle operation. Confirm the installation, electrical ratings and applicable approval requirements against the current manufacturer documentation before use.

Relevant documentation available from TE Connectivity includes the W23/W31 Series Datasheet and product-specific CAD files.
