TE P&B Circuit Breaker W23-X1A1G-15

TE P&B Circuit Breaker W23-X1A1G-15

https://www.roctexo.com/web/image/product.template/54346/image_1920?unique=99a391e
Part numbers : RX1-11-03925 , W23-X1A1G-15 , 11-03925
Unit of Measure: EA

38.26 EUR / EA 38.26 EUR 38.26 € excl. VAT

38.26 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
3 EA ready to ship Today
Order before 15:30 CET Today
Up to 16 EA ready to ship on Monday 2026-08-17
Order before 15:30 CET Today
Up to 30 EA ready to ship on Thursday 2026-08-20
Order before 15:30 CET Today
28 EA available on request, fees apply
Special order from vendor stock.

The TE Connectivity Potter & Brumfield W23-X1A1G-15 is a single-pole, push-pull thermal circuit breaker with a 15 A current rating. It is configured with a black, non-illuminated actuator and series-trip circuit function for electrical circuit protection applications.

  • Manufacturer part number: W23-X1A1G-15
  • TE Connectivity internal number: 6-1393246-6
  • Current rating: 15 A
  • Operating voltage: 240 VAC / 50 VDC
  • One-pole thermal circuit breaker
  • Push-pull button actuator; black, non-illuminated
  • Series-trip function
  • Trip time at 200%: 6–22 seconds
  • Terminal configuration: 8-32 screw terminals at 90° to each other
  • Threaded mounting bushing with two hex nuts and lockwasher; panel cut-out diameter 9.5–9.8 mm

Please verify the complete part number, electrical requirements and installation configuration against the applicable maintenance data before purchase or installation.

Documentation: TE Connectivity product page and W23/W31 series documentation.

Contact Us

Terms and Conditions

Share

P & B Part No.AMP
Rating		BeechCessnaPiperPart No.
W23X1A1G1515CB-2315A-45465811-03925


Overview

These bi-metallic single pole breakers weigh less than 2 oz. and are especially suitable for homebuilt aircraft. Used as original equipment in Beech, Cessna and Piper aircraft. Maximum operating voltages: 32 VDC and 250 VAC (to 400 Hz).

Push/Pull Actuator Thermal Circuit Breaker
    0.5 amp to 50 amp ratings may be used as on/off switch
    Cannot be reset against overload
    W23 has visible trip indicator
    Screw termination
    Trip-free operation
