Max Power USB Charging Port 15With 3A And 100With 5A Out Per Port 22-32 VDC In Dual USB-A/USB-C Pd Rear Connector

Max Power USB Charging Port 15With 3A And 100With 5A Out Per Port 22-32 VDC In Dual USB-A/USB-C Pd Rear Connector

https://www.roctexo.com/web/image/product.template/133081/image_1920?unique=782fa0f
Part numbers : RX1-10-07492 , 6430360-21 , 10-07492
Unit of Measure: EA

621.84 EUR / EA 621.84 EUR 621.84 € excl. VAT

621.84 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 5 EA ready to ship on Thursday 2026-08-13
Order before 16:00 CET on Tuesday 2026-08-11
5 EA available on request, fees apply
Special order from vendor stock.

The True Blue Power TA360-CA MAX Power USB Charger, manufacturer part number 6430360-21, is a dual aircraft charging port with one USB-A connection and one USB-C Power Delivery connection. Designed for rear panel installation, it supports both legacy USB-A cables and modern USB-C PD devices.

The USB-A port supplies up to 15 W at 3 A, while the USB-C PD port provides up to 100 W at 5 A. The charger accepts a 22–32 VDC aircraft power input and uses intelligent USB Power Delivery negotiation to provide an appropriate charging voltage for the connected device.

  • Dual USB-A and USB-C PD charging configuration
  • USB-A output: up to 15 W / 3 A
  • USB-C PD output: up to 100 W / 5 A
  • Input voltage: 22–32 VDC
  • Rear connector and panel-mount design
  • Variable USB-C PD output: 5, 9, 15 or 20 VDC
  • Built-in protection for over-current, short circuit, low input voltage, reverse polarity and over-temperature conditions
  • FAA TSO-C71 and EASA ETSO-C71 certification; qualified to RTCA DO-160G environmental conditions
  • Approximate dimensions, excluding mating connector: 38 x 26 x 50 mm
  • Mating connector kit: 9017960

This configuration is specified by the manufacturer as Starlink Mini compatible. For that use, a third-party validated USB-C-to-barrel-jack cable is required; Starlink-manufactured USB-C-to-barrel-jack cables are not compatible.

Manufacturer part number: 6430360-21
Model: TA360-CA

Aircraft installation approval and compliance must be assessed for the specific installation. Installation Manual, 9019411 | Technical Drawing
