Swift 3-1/8 Airspeed Indicator 0-180 MPH / KPH / Knots

Swift 3-1/8 Airspeed Indicator 0-180 MPH / KPH / Knots

https://www.roctexo.com/web/image/product.template/92984/image_1920?unique=5ef4b0d
Part numbers : RX1-10-06303 , ASI3-180 , 10-06303
Unit of Measure: EA

540.23 EUR / EA 540.23 EUR 540.23 € excl. VAT

540.23 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The Swift ASI3-180 is a 79 mm electronic airspeed indicator with a 0–180 MPH range and selectable MPH, km/h and knots scales. It is designed around a MEMS sensor and provides a compact panel instrument solution where multiple speed-unit indications are required.

  • Manufacturer part number: ASI3-180
  • Instrument diameter: 3-1/8 in (approximately 79 mm)
  • Airspeed range: 0–180 MPH
  • Switchable display units: MPH, km/h and knots
  • Supply voltage: 9–30 VDC
  • Installation depth: 96 mm
  • Zero adjustment via a single button to compensate for zero error
  • Airspeed correction adjustment stated as 0.7 to 1.3 of the indicated reading

The ASI3-180 combines selectable unit presentation with adjustment functions intended to support correction for installation- and system-related indication differences. Confirm suitability, installation requirements and regulatory acceptance for the specific aircraft with appropriately qualified personnel before installation.
