Swift 3-1/8 Altimeter 0-10K Medium 2 Pointer Baro Mmhg Inhg Mb

Swift 3-1/8 Altimeter 0-10K Medium 2 Pointer Baro Mmhg Inhg Mb

https://www.roctexo.com/web/image/product.template/76563/image_1920?unique=5ef4b0d
Part numbers : RX1-10-06288 , ALT3-10M2 , 10-06288
Unit of Measure: EA

583.30 EUR / EA 583.3 EUR 583.30 € excl. VAT

583.30 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The Swift ALT3-10M2 is an electronic altimeter with a 10,000 m indication range and two-pointer display. Designed for an approximately 80 mm panel cut-out, it combines analogue altitude indication with a digital barometric-pressure display.

The instrument uses a MEMS pressure sensor and provides selectable barometric-pressure units in mmHg, inHg or mb. Barometric pressure is adjusted by push button, while display brightness for the digital pressure readout is adjustable.

  • Manufacturer part number: ALT3-10M2
  • Altitude range: 0–10,000 m
  • Indication: two-pointer
  • Panel size: 3-1/8 in (Ø80 mm)
  • Installation depth: 96 mm
  • Power supply: 9–30 VDC
  • Selectable barometric-pressure units: mmHg / inHg / mb
  • Digital barometric-pressure display with adjustable brightness

A technical data sheet is referenced for this instrument series. Confirm installation suitability, aircraft documentation and applicable regulatory requirements before installation.
