Insight 8 Cylinder G9 Single Engine Bezel (Below 60 Gph)

The Insight G9 8-Cylinder Single Engine Bezel is an Insight Instrument Corporation configuration for single-engine, eight-cylinder installations with fuel flow below 60 GPH. It is identified by manufacturer part number 1210C-082 and Roctexo part number RX1-10-06231.

The G9 is a colour graphic engine-monitoring system designed to present key engine data in a clear, consolidated display. Manufacturer documentation describes G9 capability for simultaneous exhaust-gas temperature (EGT), cylinder-head temperature (CHT) and turbine-inlet temperature (TIT) indication, together with functions including fuel-flow monitoring, RPM, manifold pressure, oil temperature and pressure, outside-air temperature, electrical-system voltage, vibration analysis, probe diagnostics and SD-card data logging, depending on installation and system configuration.

• Single-engine, 8-cylinder G9 configuration
• Specified for fuel-flow applications below 60 GPH
• G9 3.125-inch bezel format, approximately 79 mm
• Colour graphical presentation with leaning-support and engine-data functions
• Manufacturer part number: 1210C-082

Please confirm the required configuration, installation requirements and applicable approval basis against the aircraft records and current Insight documentation before purchase or installation.
