Dynon Skyview Lycoming Continental 4-Cylinder Carburetor Engine Pack

Dynon Skyview Lycoming Continental 4-Cylinder Carburetor Engine Pack

https://www.roctexo.com/web/image/product.template/100860/image_1920?unique=603c35b
Part numbers : RX1-10-05532 , DYNON LYC4 CARB , 10-05532
Unit of Measure: EA

2132.21 EUR / EA 2132.21 EUR 2,132.21 € excl. VAT

2132.21 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 1 EA ready to ship on Monday 2026-08-10
Order before 17:00 CET on Friday 2026-08-07
2 EA available on request, fees apply
Special order from vendor stock.

The Dynon SkyView Lycoming/Continental 4-Cylinder Carburettor Engine Pack is an engine sensor and wiring-harness package for Dynon SkyView engine monitoring installations on carburetted four-cylinder Lycoming and Continental engines.

Dynon identifies this configuration as EMSKIT-L4C, manufacturer reference DYNON LYC4 CARB. The package supports the collection of key engine and electrical-system data when installed with the applicable Dynon engine monitoring equipment.

  • One 0–60 A current shunt
  • Fuel-pressure, manifold-pressure and oil-pressure sensors
  • One carburettor-air temperature sensor
  • Four Type J cylinder-head-temperature thermocouples
  • Four Type K exhaust-gas-temperature thermocouples
  • One oil-temperature sensor
  • Main sensor harness and CHT/EGT harness

Dynon’s current SkyView System Installation Guide lists the EMSKIT-L4C as P/N 105114-000. Review the applicable Dynon installation documentation and the aircraft/engine documentation before installation to confirm the required configuration and installation details.

Supplied as one each.
