G51 Magneto Start Combo Guard - Red

G51 Magneto Start Combo Guard - Red

https://www.roctexo.com/web/image/product.template/293017/image_1920?unique=241009f
Part numbers : RX1-05-33401 , MSSCG1R , 05-33401
Unit of Measure: EA

117.80 EUR / EA 117.8 EUR 117.80 € excl. VAT

117.80 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
2 EA available on request, fees apply
Special order from vendor stock.

The G51 Mag/Start Combo Guard Red is a compact protective and labelling panel for a magneto and start switch installation. Manufacturer part number: MSSCG1R.

CNC-machined from billet 6061-T6 aluminium, the guard has a red Cerakote finish and white MOPA fibre-laser marking. Its toggle-switch layout provides a clear visual indication of magneto switch positions while helping protect the controls from unintended operation.

  • Red Cerakote finish (Ruby Red H-306)
  • CNC-machined billet 6061-T6 aluminium construction
  • Approximate overall dimensions: 68 mm wide × 45 mm high × 20 mm deep
  • Magneto switch holes accept toggle switches with 7/16 in threaded bushings
  • Start switch opening: 5/8 in diameter, for P1 threaded-bezel switches
  • White laser-marked legends
  • Supplied with a drill template; anti-rotation washers may be used if required but are not included

Switches are not included. Verify switch dimensions, installation requirements and aircraft approval status before purchase and installation.
