Cleveland 40-113 Series Aeroluxe Wheel Assembly - Obsidian Disc - White

The Cleveland Wheels & Brakes AeroLuxe main wheel assembly, P/N 40-113-0511, is supplied in white with an Obsidian brake disc. It is a 40-113 series external, tube-type wheel assembly with a 6.00-6 rim configuration.

The AeroLuxe finish uses a two-component polyurethane enamel coating designed for high-performance use and resistance to lubricants and oils. The Obsidian brake disc is corrosion resistant and laser marked for clear part-number identification.

• Manufacturer: Cleveland Wheels & Brakes
• Manufacturer part number: 40-113-0511
• White AeroLuxe finish
• Obsidian brake disc
• External wheel interface; tube-type configuration
• 6.00-6 rim and tyre size; 4-ply configuration
• Split-rim wheel design with tapered roller bearings, moulded grease seals and high-strength through-bolts
• Manufacturer-listed matched brake assemblies: 30-75 and 30-75A

Please verify the required part number, approved installation data and maintenance documentation for the specific aircraft before installation.

Manufacturer documentation: 40-113 Exploded View and Cleveland Technician’s Service Guide.
