Andair CK375M-14-Brp Check Valve

https://www.roctexo.com/web/image/product.template/34962/image_1920?unique=182fd28
Part numbers : RX1-05-14969 , CK375-M-14-BRP , CK375M-14-BRP , 05-14969
Unit of Measure: EA

295.13 EUR / EA 295.1278600269179 EUR 295.13 € excl. VAT

295.13 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
2 EA ready to ship Tomorrow
Order before 15:30 CET Tomorrow

The Andair CK375M-14-BRP is a compact, one-way check valve from the CK375 series. It is designed to permit flow in the indicated direction while preventing reverse flow; an arrow on the valve body identifies the required flow direction.

This configuration includes a bleed provision to allow pressure to bleed back through the internal shuttle arrangement. The valve body is manufactured from aluminium and anodised for added corrosion protection.

  • Manufacturer part number: CK375-M-14-BRP
  • Also identified as: CK375M-14-BRP
  • CK375 series complete-closure check valve
  • Bleed configuration
  • Listed with an AN-6 (3/8 in) fitting
  • Approximate product weight: 23 g
  • Unit of supply: each

Verify the part number, flow orientation, fitting arrangement and suitability for the intended installation against the applicable aircraft documentation and manufacturer technical data before installation.

Documentation: Andair Check Valves technical data sheet.

Contact Us
Orders with purchased items below 100.00 € incur a small order fee of 10.00 €. Both amounts exclude VAT. Shipping, other fees and core deposits do not count towards the limit.

Terms and Conditions

Share

art NumberModelBleedFittings
05-14969CK375-M-BRP----

Overview

Built from aircraft grade Aluminum and anodized for corrosion protection this lightweight and compact unit is excellent. The check valve is ideal for tank vents and high pressure fuel pump bypass lines. Its extremely light weight internal shuttle operates with the slightest pressure yet the internal O-ring seals allow the unit to be used up to 50 PSI.

Other qualities include break out pressure less than 1 PSI, great flow characteristics around shuttle, and bleed allows shuttle to weep off pressure in the event of a blocked line. Features AN-6 (3/8") fitting on bottom. Valve measures 5/16" dia. x 2.75" long.
