Cleveland Wheel Assembly 40-120C

Image for illustration only. It may show a product series rather than the exact product offered.

Cleveland Wheel Assembly 40-120C

https://www.roctexo.com/web/image/product.template/72118/image_1920?unique=dddfb88
Part numbers : RX1-05-13502 , 40-120C , 05-13502
Unit of Measure: EA

3028.41 EUR / EA 3028.41 EUR 3,028.41 € excl. VAT

3028.41 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Not in stock
Available to order. Lead times vary.

The Cleveland Wheel & Brake Systems 40-120C is a main wheel assembly designed to support aircraft loads during landing and ground manoeuvring and to transmit braking forces to the ground.

This divided wheel design incorporates inner and outer wheel halves with a brake disc, secured by tie bolts, washers and nuts. The assembly uses tapered roller bearings and moulded grease seals to support bearing protection and lubricant retention. Its split-rim construction facilitates tyre mounting during maintenance.

  • Manufacturer: Cleveland Wheel & Brake Systems
  • Manufacturer part number: 40-120C
  • Roctexo part number: RX1-05-13502
  • Wheel interface: External
  • Configuration: Tube type
  • Rim size: 6.00-6
  • Wheel finish: Silver
  • Matched brake: Cleveland 30-83A
  • Standard brake disc: 164-21600
  • Manufacturer-listed certification type: FAA-TSO-C26b

For maintenance, overhaul and installation requirements, consult the applicable aircraft maintenance documentation and Cleveland technical data. Confirm approved part-number applicability for the specific aircraft before installation.

Manufacturer documentation: Component Maintenance Manual | 40-120C Exploded View
