Nylon Tubing 44Nsr 1/4 Natural

Nylon Tubing 44Nsr 1/4 Natural

https://www.roctexo.com/web/image/product.template/1287/image_1920?unique=e5f6e6c
Part numbers : RX1-05-12488 , 44NSR-N , 05-12488
Unit of Measure: FT

2.13 EUR / FT 2.13 EUR 2.13 € excl. VAT

2.13 EUR / FT excl. VAT

Not Available For Sale

This combination does not exist.

Availability
50 FT ready to ship on Monday 2026-08-17
Order before 15:30 CET on Monday 2026-08-17
Up to 232 FT ready to ship on Thursday 2026-08-20
Order before 15:30 CET on Monday 2026-08-17
Up to 343 FT ready to ship on Monday 2026-08-24
Order before 15:30 CET on Monday 2026-08-17
400 FT available on request, fees apply
Special order from vendor stock.

Natural-colour Nylo-Seal type NSR semi-rigid nylon tubing for fluid-line installations. Manufactured from Nylon-II, this tubing is described as resistant to flexural fatigue and intended for applications involving vibration or tube movement.

  • Manufacturer part number: 44NSR-N
  • Outside diameter: 6.35 mm
  • Wall thickness: 1.27 mm
  • Listed burst pressure: 2,120 psi (approximately 146 bar)
  • Minimum bend radius: 14 mm
  • Natural finish
  • Unit of measure: foot

The source identifies NSR tubing for hydraulic brake-line use where its suitability has been verified for the specific installation. Use SAE fittings; brass Poly-Flo fittings are not suitable for this NSR tubing.

Contact Us

Terms and Conditions

Share

TypePart NumberO.D.
(In.)		Wall (In.)Burst
Pressure
(PSI)		Min.
Bend
Radius		Wt.
(Lb./Ft.)
NSR Tubing - Natural05-124881/4.05021209/16.015

Overview

Nylo-Seal type "N":
Semi-rigid natural color (N) tubing is made of Nylon-II and is far superior to other types of Nylon tubing. It does not depend on moisture for flexibility and does not become brittle. It has excellent resistance to flexural fatigue and can be used where there is vibration or tube movement. Self-extinguishing under A.S.T.M. Test D635-44.

N Tubing is rated to 1000 lbs. and is excellent for instrument lines and other low pressure applications.


Nylo-Seal type "NSR":
Semi-rigid black (B) color or Natural (N) tubing is made of Nylon-II and is far superior to other types of Nylon tubing. It does not depend on moisture for flexibility and does not become brittle. It has excellent resistance to flexural fatigue and can be used where there is vibration or tube movement.

NSR Tubing is rated to 2500 P.S.I. and is excellent hydraulic brake lines after verifying it is appropriate tubing for your application.

Note: Brass Poly Flo fittings cannot be used with NSR tubing listed. Use SAE fittings.
