Flanged Bushing FF620-01

Image for illustration only. It may show a product series rather than the exact product offered.

Flanged Bushing FF620-01

https://www.roctexo.com/web/image/product.template/98276/image_1920?unique=ca5c425
Part numbers : RX1-04-01654 , FF620-01 , 04-01654
Unit of Measure: EA

1.29 EUR / EA 1.29 EUR 1.29 € excl. VAT

1.29 EUR / EA excl. VAT

Not Available For Sale

This combination does not exist.

Availability
Up to 3 EA ready to ship on Monday 2026-10-26
Order before 17:00 CET Tomorrow
Up to 5 EA ready to ship on Thursday 2026-10-29
Order before 17:00 CET Tomorrow
95 EA available on request, inbound freight fee of 60 EUR applies
Special order from vendor stock.

The FF620-01 is an Oilite bronze flanged bushing for general hardware and mechanical assembly use. The integral flange provides a locating surface where a flanged bushing configuration is required.

  • Manufacturer part number: FF620-01
  • Material: Oilite bronze
  • Nominal bore diameter: 12.75 mm
  • Outside diameter: 15.9 mm
  • Body length: 12.7 mm
  • Flange outside diameter: 22.2 mm
  • Flange thickness: 1.6 mm
  • Unit of measure: each

Please verify the part number and dimensions against the applicable maintenance data or assembly requirements before installation.
