Solid Aluminum Rivet MS20426Ad-3-5
Part Number(s): AN426AD-3-5, MS20426AD-3-5
Unit of Measure Name:
lb
Internal Reference:
RX1-AN426AD-3-5
| Part No. | Type | Dia. x Length | Qty./Lb. |
|---|---|---|---|
| AN426AD-3-5 | 2117 Hard | 3/32 x 5/16 | 3478 |
Overview
| Note: quantities must be entered in decimal format. (i.e. 0.25 for 1/4, 0.50 for 1/2, etc). Minimum Purchase 1/8 lb. (qty .13). "A" rivets are "soft". They are fabricated from 1100-grade aluminum and have a tensile strength of 16,000 PSI. "AD" rivets are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. Prices below are for 1lb. quantities. All rivets can be purchased in 1/4 lb. (use qty .25) and 1/8 lb. (use qty .13) packages. AN470 (MS20470) AN426 (MS20426). AN426 are 100° rivets. |
